Description: I need a joint to insert four PVC pipes (or other dowels) into. The purpose is to make it easy to make a pyramid frame. The angle from one corner of the pyramid at the apex to an adjacent corner needs to be about 16.3 degrees.

Project views: 178

Project status: New Now accepting: Designs

Design Type-Tier: technical-bronze

Design Price: US$25.00 | Paid: US$25.00

Fabrication Price: Payment Pending

PROJECT IS PUBLIC - all registered You3Dit designers and fabricators can review your project and submit 3D models and fabrication quotes to this project. This dramatically improves your cost, quality and schedule options.

Order Number: 20160207200623-366-10-1

Material desired: plastic

Quantity desired: 3

Additional Information: Ideally this 3D model would be scalable to allow for printing joints for different sized pipes. Also, I'd like the top of the joint to be pointed. The joint should accommodate a half inch pvc pipe. Due to how small the angle is, there is no need to space the pipes apart, get them as close together as is practical while maintaining proper proportions. The top of the joint should be a point, not rounded. Thank you for your help.
